We are your driver
KEBA drive controllers get the maximum in dynamics and precision from your machine. Your particular benefit is our solution and consulting competence in automation with electric drives. Thanks to their high flexibility e.g. in networking, motor and encoder interfaces or safety technology, our servo controllers and motors can be perfectly and quickly integrated into your automation system.
Your benefits at a glance
- Reliable partnership
- High solution competence
- Distinct industry knowledge
- Future-proof
- Long-term availability
Convincing Highlights
Our drive systems are the basis for performance, productivity and safety of your machine. The modularity and the wide range of products and services guarantee you optimal and fast integration into the machine automation at any time.
- Energy-efficient multi-axis systems (230-480 V AC with 1.5 A-450 A)
- Flexible single-axis systems (24 V DC-480 V AC with 2 A-450 A)
- Industry-specific variants and systems
- Scalable safe motion solutions according to PLe/SIL3
Our Drive Portfolio
KEBA offers you a comprehensive portfolio of drive systems. You will always find the right solution with us, whether for your compact machine with only one drive axis or for complex multi-axis machines.
We are also your partner if the application requires special or country-specific drive solutions.
Energy - Efficient Multi - Axis Drive Controllers
Dynamic, precise and yet compact: These characteristics for increasing productivity characterize our multi-axis systems. Up to three axes are combined in one module without limiting the performance of each individual axis. Coupled with the best energy utilization via the common DC bus, we offer you future-proof drive solutions.
Your benefits:
- Central power supply units, also with sinusoidal mains feedback
- Compact design allows mounting close to the motion process
- Easy system installation due to reduced component variety
- Fast system and series commissioning with sophisticated tools
Our Multi - Axis Drive Controllers
KeDrive D3 - Compact
The compact drive system with single, double and triple axis controllers and integrated safety technology. The power supply units can be extended with a power recovery system.
- Axis controller: 1.5 A-210 A
- Power supplies: 10 kW-120 kW, integrated 24 V power supply optional
- EtherCAT (CoE), PROFINET IRT
ServoOne DC - „High Power“
Powerful drive system with high fieldbus variance for the upper power range. As an alternative to the power supply units, DC supply via ServoOne single axes (shared DC) allows a cost-effective power supply.
- Axis controller: 4 A-450 A
- Power supply units with sinusoidal power recovery: 26 kW-360 kW
All - In - One Single - Axis Drive Controller
Our single-axis controllers directly integrate the power supply unit and partly also the EMC line filter. This saves space and simplifies system installation. A scalable portfolio always offers the optimal drive solution from simple positioning tasks to dynamic precision movements with torque or linear motors.
Your benefits:
- Scalable safe motion solutions integrated
- Standardized fieldbuses, including EtherCAT, PROFINET, Sercos, POWERLINK and CANopen
- Open, flexible motor interface for own and third-party motors
- On-board single-axis PLC for individual motion profiles
Our Single - Axis Drive Controllers
A wide performance range, best control technology, various interfaces in communication and motor connection as well as the CODESYS PLC allow extreme flexibility and a wide range of applications.
- 4 A-450 A at 3x400 V AC
- Air or liquid cooled systems
- Integrable multi-axis safety control
Servoone Junior - Small But Powerful
Specialized in the lower performance range, the "junior" has all the technological genes of the entire family.
Full functional compatibility and handling within the ServoOne family is guaranteed at all times.
- 3 A-8 A at 1/3 x 230 V AC
- 2 A-16 A at 3 x 400 V AC
- Up to 300% overload capacity
c-line Drives - efficient positioning converter
Optimized drives for open or closed-loop operation of different motor variants. Integration into the automation solution is done via CANopen or PROFIBUS-DP.
- 2.4 A-7.1 A (0.375 kW-1.5 kW) at 1x230V AC
- 2.2 A-250 A (0.75 kW-110 kW) at 3x400 V AC
- Integrated mains filter and 24 V supply
CDF3000 - Low Voltage Drives
Our smallest servocontroller impresses with all the performance of the c-line drives.
- 8 A at 24 V-48 V DC
- 200% overloadable
- CANopen communication interface
- STO safety function (SIL3/PL e)
Industry-specific drive solutions
Based on our flexible modular drive system and our knowledge of the industry, we implement your special solution quickly and reliably.
Your benefits:
- Reliable partnership with industry experts
- Perfect price/performance ratio
- Compact automation solutions
- All industry standard functions and interfaces integrated
Our industry-specific drive solutions
ServoOne for high speed
The drive controller with high output frequencies, especially for energy-efficient turbomachinery and lowest shaft power loss.
PitchOne for pitch systems
Our latest technology for pitch applications scores with network-independent power supply and functional safety of the last generation.
PitchMaster II+ for pitch systems
The "state of the art" in pitch for wind turbines. Robust, highly integrated with TÜV and GL approval. And proven 100,000 times over.
Drives for plastics machinery
Complete hardware and software package including service, reliable application, and broad functionality: The KeDrive D3 drive system for all plastics machines helps you create smart, sustainable, and cost-efficient solutions for your multi-axis applications.
Country specific drive solutions
The worldwide use of our servo controllers also requires the provision of country or continent-specific interfaces as well as compliance with special standards and regulations.
In addition to the general flexibility of our servo controllers, KEBA also offers you country-specific models for this purpose.
Your benefits:
- Perfect integration into local automation networks with special hardware and software interfaces
- Adaptation to worldwide different mains voltages
- Worldwide uniform quality and functionality
- International Development Network
- Regional repair and installation service
Our drive solutions for the Asian region
ServoA - High-Performance
The servo controller is integrated into a wide range of control applications via EtherCAT. The integrated PLC allows flexible motion profiles. A display for status indication and parameterization is integrated.
- 400 W-1500 W at 1/3x230 V AC
- 750 W-9000 W at 3x400 V AC
- STO safety function (SIL3/PL e)
- Suitable local servo motor series
ServoC plus - efficient and simple
The servo controller is integrated into a wide range of control applications via the CANopen, RS485 or pulse/direction interface. Preset motion solutions simplify commissioning.
- 400 W-1500 W at 1/3x230 V AC
- 750 W-9000 W at 3x400 V AC
- Suitable local servo motor series
Digital control technology that moves
Control technology makes the difference at KEBA.
A sophisticated control structure and predictive pre-controls allow the greatest possible dynamics with the highest level of accuracy.
Mechanical deficiencies are corrected online with mathematical methods or hidden. These include encoder errors, errors in the mechanical transmission path, friction and cogging torques or resonance frequencies.
Autotuning for easy commissioning identifies the machine mechanics and parameterizes the control loops quickly and reliably.
To reduce downtimes, the drive system and the coupled mechanics are constantly monitored. Defects are diagnosed quickly and wear is diagnosed in advance. The internal evaluation of all data ensures fast analyses, only the results are transmitted to the factory automation in real time.
Fast and safe system integration
Our modular drive controllers can be perfectly integrated into the KEBA or a third-party automation system.
Flexible communication
"One Drive fits all" - Standardized interfaces such as EtherCAT, PROFINET or CANopen allow uniform drive technology and constant motion quality even when using different controllers.
Open motor interface
In addition to the extensive KEBA motor program, our drive controllers with their multi-encoder interface and various control models are open for special or third-party motors. The automatic user-guided motor identification optimizes all control parameters.
Advanced commissioning tools
Tools that have been tried and tested over many years ensure perfect commissioning with their many assistant functions. These include guided commissioning, a real-time oscilloscope or frequency response analysis for precise detection and compensation of mechanical deficiencies.
Scaleable Safe Motion Packages
All drive controllers are already equipped with the STO function as standard. Additional safety functions and packages ensure compliance with applicable regulations, depending on the application. Safe motion monitoring can be activated and parameterized via I/O or FSoE fieldbus communication.
